Артикул: MP953A5039/U Pneumatic Actuator, Valve Operator Honeywell
Overview MP953 Pneumatic Valve Actuators are suitable for use in conjunction with Honeywell valves V5011, V5013, V5015, V5016, V5025, V5049, V5050, V5328, and V5329 to provide proportional control of steam or hot and cold water in HVAC systems.
Product Specifications Hazmat Information Dimensions (in.) 5-7/16 in. diameter x7-9/16 in. maximum high Dimensions (mm) 130 mm diameter x 192 mm maximum high Maximum Safe Operating Pressure (psi) 20.3 psi Maximum Safe Operating Pressure (kPa) 140 kPa Temperature Range (F) Maximum 158 F Temperature Range (C) Maximum 70 C Used With V5011, V5013, V5015, V5049, V5050, V5016, V5025, V5328, V5329 Comments Rolling Diaphgram Actuator Type Valve Actuator with poisitioner Fail Safe Mode Stem action extends Stroke (in.) 7/8 in. Stroke (mm) 20 mm Action Direct or Reverse acting Air connections Barb fitting for PE tube 6x1 or 1/4 in. outer diameter
